T-MOTOR FT800 VTX 5.8G 48CH Video Transmission | Mechfpv of Shenzhen

description:

The T‑MOTOR FT800 is a high‑performance 5.8 GHz analog FPV video transmitter built for freestyle, long‑range and racing drone platforms. It features an integrated aluminum alloy heat‑dissipating shell to handle thermal load under high‑power transmission. It supports multi‑level adjustable output power: PIT / 25 mW / 200 mW / 500 mW / 800 mW, with total 48 selectable channels including RaceBand. Running SmartAudio 2.1 protocol, users can adjust channels & power directly via BetaFlight OSD.

Wide operating voltage input from 7‑36 V DC supports 2‑8S LiPo battery setups. Compact 20×20 mm mounting hole layout and light‑weight 7.58‑gram design fit most 5‑7‑inch FPV frames. Equipped with MMCX antenna connector. It provides stable analog CVBS video output, anti‑interference performance for multi‑pilot flying events. Ideal for long‑range cruising, freestyle and racing FPV drone builds.

brand: T‑MOTOR

sku: TM‑FT800‑VTX‑58G

offers:

• 5.8 GHz analog VTX, 48 channels including RaceBand

• Adjustable power levels: PIT / 25 mW / 200 mW / 500 mW / 800 mW

• SmartAudio 2.1 protocol, OSD parameter configuration supported

• 7‑36 V wide‑voltage input, compatible with 2‑8S LiPo

• Aluminum alloy heat‑sink housing for reliable high‑power operation

• MMCX antenna connector; 20×20 mm mounting footprint, only 7.58 g

• Stable CVBS analog video output, optimized for multi‑pilot flight scenarios

availability: In Stock, Fast Shipping
